DEHLER 46 SQ

EX_02_220407_DEHLER 46SQ EXTERIEUR 05 P08_RGB.jpg
EX_17_220407_DEHLER 46SQ EXTERIEUR 05 P06_RGB.jpg

A TRUE DEHLER

Typical Dehler performance paired with generous comfort – the Dehler 46 SQ is a masterpiece on the water. The interaction between sporty lines, the finest craftsmanship and unique design creates a 46-foot performance yacht full of superlatives.

STRENGTHS & SOLIDITY

Being the top of the range the 46 SQ enjoys ALL of the features and benefits that Dehler have achieved, having built over 25,000 boats.

The hull is vacuum infused using epoxy based resins to achieve strength and low weight. The internal subframe structure is carbon to further stiffen without compromise and the keel is designed with a low centre of gravity to ensure this investment in technology and high tech materials is rewarded on the water.

IN_03_220408_DEHLER 46SQ INTERIEUR 06 P03_RGB.jpg
IN_06_220408_DEHLER 46SQ INTERIEUR 06 P04_RGB.jpg

GALLERY

1
press to zoom
2
press to zoom
3
press to zoom
4
press to zoom
5
press to zoom
6
press to zoom
7
press to zoom
8
press to zoom
9
press to zoom
10
press to zoom
11
press to zoom
12
press to zoom
13
press to zoom
14
press to zoom
15
press to zoom
16
press to zoom
17
press to zoom
18
press to zoom
1/2

LAYOUT

EX_20_220412_DEHLER 46SQ EXTERIEUR 05 P11_RGB.jpg

VIDEO

SPECIFICATIONS

LOA: 14.94 m
LWL: 12.90 m
Beam: 4.35 m
Draft: 2.25 m ( standard ) | 2.58 m ( competition ) | 1.85 m ( shallow ) | 2.45 m ( west coast )

Displacement: 11500 Kg ( standard ) | 11200 Kg ( competition ) | 11990 Kg ( shallow ) | 11050 Kg ( west coast )
Ballast: 3500 Kg ( standard ) | 3150 Kg ( competition ) | 3850 Kg ( shallow ) | 3850Kg ( west coast )
Engine: VolvoPenta D2-55 ( 55Hp )

Fresh water: approx. 450 l
Fuel tank: approx. 210 l
CE Certificate: A ( ocean )

Mast length above WL: 21.23 m ( standard ) | 22.20 m ( competition )
Total sail area: 116.73 m2 ( standard ) | 126.79 m2 ( competition )
Main sail: 64.1 m2 ( standard ) | 70.52 m2 ( competition )
Furling jib (106%): 52.63 m2 ( standard ) | 56.27 m2 ( competition )
Spinnaker: 174.5 m2 ( standard ) | 150 m2 ( competition )
Gennaker: 185.38 m2 ( standard ) | 214.0 m2 ( competition )

Rig:
I 18.1 m ( standard ) | 18.9 m ( competition )
J 5.50 m
P 17.68 m ( standard ) | 18.70 m ( competition )
E 6.25 m ( standard ) | 6.55 m ( competition )

RIGG AND SAILS
9/10 rig, tapered masttop – Two spreader anodised aluminium mast and boom – Under deck furling system for jib – Single line reefing system – Rod kicker – Stainless steel standing rigging – Hydraulic backstay adjuster – ”German” mainsheet system – Main and jib halyard lead aft to cockpit – Main and jib sheets – Main sail fully battened with 2 reefs Elvström FCL

Design: judel/vrolijk & co
Interior: Dehler
